Load capacity/Rated load: 1600KG
Overall length: 1540 MM
Overall width:560/680MM
Turningradius:1350MM
| Manufacture's type designation | HOPPER | |||
| Model | CBH16 | CBD16 | ||
| Power type | Electric Electric | Electric Electric | ||
| Type of operation | Pedestrian | Pedestrian | ||
| Load capacity/rated load | t | 1.6 | 1.6 | |
| Load center distance | mm | 600 | 600 | |
| Total weight(with lithium battery) | kg | 145/150 | 155/160 | |
| Driving wheel size | mm | ∮210x70 | ∮210x70 | |
| Tyre size (Front) | mm | ∮80x70 | ∮80x70 | |
| Wheels material | PU coated iron core | PU coated iron core | ||
| Overall length | L1 | mm | 1540 | 1540 |
| Overall width | B | mm | 560/680 | 560/680 |
| Height of operating Handlebar(Max) | H3 | mm | 1220 | 1220 |
| Frame height | H4 | mm | 560 | 560 |
| Lifting height(Max) | H1 | mm | 190 | 190 |
| Lifting height(Min) | H | mm | 85 | 85 |
| Fork length | L | mm | 1150 | 1150 |
| Fork Dimension | B1 | mm | 160 | 160 |
| Turning radius | R | mm | 1350 | 1350 |
| Center distance between front and rear wheels | L2 | mm | 1220 | 1220 |
| Traveling speed(laden/ unladen) | km/h | 4.5 | 4.5 | |
| Max. Gradeability (laden/unladen) | % | 44260 | 44260 | |
| Drive motor rating | kw | 0.75 | 0.75 | |
| Lift motor rating | kw | / | / | |
| Battery voltage/capacity | V/Ah | 24/20 | 24/20 | |
High-quality hydraulic power unit, low noise, low vibration, strong sealing, Precise electrical limit switch, accurately control the maximum lifting height, prevent damage to the motor; The mechanized design of the control handle makes it convenient for left and right hand operations, simple operation, and improved driving comfort. The drive motor adopts an AC motor, which is maintenance-free, has a long life, No level to control the driving speed, and meet different driver rhythm;
